25x25x3mm-100x100x16mm
Ruiyang
7222400000
Stainless Steel Angle steel also called stainless steel angle Bar,Stainless Steel Angle commonly used for framing brackets, bracing, shelves, structural supports, construction material,architectural trim and molding, and other parts requiring machining, welding, grinding, or polishing. In the flields of Industries: residential, industrial, manufacturing, automotive, interior design, natural gas, oil refining, food processing, architecture, construction
Especially Type 304, also known as 18-8 stainless, is the most versatile and widely used stainless steel – its lack of magnetism, high corrosion resistance, and good mechanical properties make it a good all-purpose stainless grade. Stainless 304/304L withstands rusting from most oxidizing agents, has good mach inability, high tensile strength, and good drawing, forming and stamping properties.
Stainless steel type Grade:
| ASTM201,202,205,301,303,302,304,304L,305,308,308L,309,309L, 310,310S,316,316L, 316Ti,316LN,317,317L, 321,329,347,409,410,416,420,430,430F,431,446, 630,631,2205,S31803, s32750 or customed |
Manufacture Standard： | GB/T4227,ASTM A276, EN 10272, GB 9787,SUS,JIS, EN, DIN,
|
Sizes： | 25X25X3-100X100X16 |
Supplied conditions： | Annealed for Austenite Pickled or Sand blasting |
Polished | |
process of angle steel bar | rolled |
bend | |
welded | |
Max bending per meter | 4mm/m |
0.4% Max bending: | ≤0.4% length/pcs.(angle size above 5#),According to the negotiation by two sides, supplier can provide angle whose max bending 0.4% length/pcs |
twist | Equilateral Angle Steel mustn’t have obvious twist. ±2°Shape: Right angle Tolerance is 90° ±2° |
Mechanical Property of SS Angle after Heat Treatment should in accordance with the following Table.
Heat Treatment |
Grade | Tensile Test | Hardness Test | |||||
σ0.2 | σb Mpa | δ 5% | HB | HRB | HV | |||
（Min） | （Max） | |||||||
Solution | AISI304 | 205 | 205 | 40 | 187 | 90 | 200 | |
AISI304L | 205 | 520 | 40 | 187 | 90 | 200 | ||
SUS304L | 175 | 480 | 40 | 187 | 90 | 200 | ||
AISI316 | 205 | 520 | 40 | 187 | 90 | 200 | ||
AISI316L | 175 | 480 | 40 | 187 | 90 | 200 | ||
AISI321 | 205 | 520 | 40 | 187 | 90 | 200 | ||
AISI310 | 205 | 520 | 40 | 187 | 90 | 200 | ||
Anneal | AISI410 | 205 | 450 | 40 | 183 | 88 | 200 | |
Size Tolerance of Hot-Rolled Stainless Steel Equilateral Angle Bar（GB4227） （Unit）：mm
Side AxB | Side Tolerance | Thickness | |||||||||
3 4 5 6 7 8 9 10 11 12 | |||||||||||
Thickness Tolerance | |||||||||||
20x20 | ±1.5 | ±0.4 | |||||||||
25x25 | ±1.5 | ±0.5 | ±0.5 | ±0.5 | |||||||
30x30 | ±2.0 | ±0.5 | ±0.5 | ±0.5 | ±0.5 | ||||||
40x40 | ±2.0 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | |||||
50x50 | ±2.0 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | |||||
60x60 | ±3.0 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | ±0.6 | |||||
65x65 | ±3.0 | ±0.6 | ±0.6 | ±0.7 | ±0.7 | ±0.7 | |||||
70x70 | ±3.0 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | |||||
75x75 | ±3.0 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | |||||
80x80 | ±3.0 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | ±0.7 | |||||
90x90 | ±3.0 | ±0.7 | ±0.7 | ±0.7 | ±0.8 | ±0.8 | ±0.8 | ||||
100x100 | ±4.0 | ±0.7 | ±0.7 | ±0.7 | ±0.8 | ±0.8 | ±0.8 | ||||
Features of angle stainless steel Bar:
1)high corrosion resistance,
2)good oxidation resistance,
3)non-hard enable by heat treatment, solution treatment annealing, excellent weldability,
4)good machinability, good drawability, good formability,
5)high tensile strength, non-magnetic
Angle stainless steel size rolled detailed:
25mm*25mm*3mm | 75mm*75mm*6mm |
25mm*25mm*4mm | 75mm*75mm*7mm |
25mm*25mm*5mm | 75mm*75mm*8mm |
30mm*30mm*3mm | 75mm*75mm*9mm |
30mm*30mm*4mm | 80mm*80mm*7mm |
30mm*30mm*5mm | 80mm*80mm*8mm |
40mm*40mm*3mm | 80mm*80mm*9mm |
40mm*40mm*4mm | 80mm*80mm*10mm |
40mm*40mm*5mm | 63mm*63mm*5mm |
50mm*50mm*3mm | 63mm*63mm*6mm |
50mm*50mm*4mm | 63mm*63mm*7mm |
50mm*50mm*5mm | 63mm*63mm*8mm |
50mm*50mm*6mm | 65mm*65mm*5mm |
60mm*60mm*5mm | 65mm*65mm*6m |
60mm*60mm*6mm | 65mm*65mm*7mm |
60mm*60mm*7mm | 65mm*65mm*8mm |
60mm*60mm*8mm | 100mm*100mm*8mm |
70mm*70mm*6mm | 100mm*100mm*9mm |
70mm*70mm*7mm | 100mm*100mm*10mm |
70mm*70mm*8mm | 100mm*100mm*12mm |
70mm*70mm*9mm | 100mm*100mm*14mm |
Welcome contact us for stainless steel angle steel bar inquiry.
Cutting to length,drill,polished,welded angle we all could supply you one stop Service,when you buy stainless steel angle steel,please mail us info@topqualityalloy.com for inquiry and order.
