Incoloy 926

Views: 0     Author: songalloy     Publish Time: 2021-11-18      Origin: SHAANXI RUIYANG IMPORT AND EXPORT CO.,LTD

Alloy 926 is a super austenitic stainless steel with a density of 8.1g/cm3.

The Incoloy 926 alloy maintains excellent corrosion resistance in harsh environments such as high temperature, seawater or flue gas desulfurization equipments.

Incoloy alloy 926 performance data is better than 316 stainless steel,317 stainless steel,super austenitic stainless steel 904L and duplex stainless steel 2205.In some cases,Alloy 926 is comparable to Hastelloy and titanium plates.

Alloy 926 is a kind of high corrosion resistance and high economy stainless steel.

Standard reference of alloy 926
The United States
ASTM A240-15a
UNS N08926
ASTM B625-05
Germany
EN 10088-1:2005
1.4529
X1NiCrMoCuN25-20-7

 N08926 and 1.4529 Chemical components as below:


C
Si
Mn
S
P
Ni
Cr
Mo
Cu
N
N08926
≤0.50

≤0.010

24~26
19~21
6.0~7.0
0.5~1.5
0.15~0.25
1.4529≤0.020
≤0.50

≤0.010
≤0.030
24~26
19~21
6.0~7.0
0.5~1.5
0.15~0.25

Incoloy alloy 926 Material performance

(1) Because of the high content of chromium and molybdenum,the pitting corrosion resistance and gap corrosion resistance in the environment of high concentration of chloride ions are very excellent.

(2) In the environment of pitting corrosion, gap corrosion and other problems of SUS329J4L, 926 can also play its excellent characteristics.

(3) Because of the austenitic metallographic structure, it has high ductility, toughness and good workability. Alloy 926 applications as below:

Seawater environment: desalination plant, seawater heat exchanger, condenser tube, etc. High concentration chloride environment: flue gas desulfurization equipment, pulp and paper industry, various bleaching equipment, etc. Containing high concentration of salt environment: resin manufacturing equipment, chemical reaction containers, pipelines, etc

We are one of Nickel-based super alloy 926 supplier,Incoloy 926 products supplier,when you need 926 alloy bars,926 alloy plate,926 alloy flange,926 alloy pipes and fasteners,please contact us freely.
