M3-M36
RuiYang
810890
ISO 10511 Titanium Hexagon Thin Nuts Prevailing Torque Type Hexagon Thin Nuts-Non-Metalic Insert produce and supply,we will adhere to the "quality first,credibility first"business philosophy.To customer satisfaction for the purpose.
We are an audited titanium fasteners supplier by SGS and BV,with own professional factory could do soonest delivery with good quality and pretty competitive price.
ISO 10511 Titanium Hexagon Thin Nuts-Prevailing Torque Type Hexagon Thin Nuts-Non-Metalic Insert type details sizes and drawings as below:
d | P | e | h | k | s | ||
Pitch | min | max | min | min | max | min | |
M3 | 0.5 | 6.01 | 3.9 | 3.42 | 1.55 | 5.5 | 5.32 |
M4 | 0.7 | 7.66 | 5 | 4.52 | 1.95 | 7 | 6.78 |
M5 | 0.8 | 8.79 | 5 | 4.52 | 2.45 | 8 | 7.78 |
M6 | 1 | 11.05 | 6 | 5.52 | 2.9 | 10 | 9.78 |
M8 | 1.25 | 14.38 | 6.76 | 6.18 | 3.7 | 13 | 12.73 |
M10 | 1.5 | 17.77 | 8.56 | 7.98 | 4.7 | 16 | 15.73 |
M12 | 1.75 | 20.03 | 10.23 | 9.53 | 5.7 | 18 | 17.73 |
（M14） | 2 | 23.35 | 11.32 | 10.22 | 6.42 | 21 | 20.67 |
M16 | 2 | 26.75 | 12.42 | 11.32 | 7.42 | 24 | 23.67 |
M20 | 2.5 | 32.95 | 14.9 | 13.1 | 9.1 | 30 | 29.16 |
M24 | 3 | 39.55 | 17.8 | 16 | 10.9 | 36 | 35 |
M30 | 3.5 | 50.85 | 22.2 | 20.1 | 13.9 | 46 | 45 |
M36 | 4 | 60.79 | 25.5 | 23.4 | 16.9 | 55 | 53.8 |
We do hope to supply our clients right goods with best price.
Welcome contact us buy ISO 10511 Titanium hexagon thin nuts with Prevailing Torque Type-Non-Metalic Insert and related Ti nuts and bolts in titanium fasteners,also stainless steel fasteners just mail us info@topqualityalloy.com with necessary sizes and quantity.
