M0.6-M16
RuiYang
GB/T867 Stainless Steel Round Head Rivets mainly used for riveting with large transverse load,ss reviets the most widely used.
The characteristic of stainless steel riveting is that it cannot be disassembled. If the two riveted parts are to be separated,the rivet must be destroyed.
The details of GB/T867 Stainless Steel Round Head Rivets:
Stainless steel Round head rivets sizes we supply as below
d | d | dk | k | R | r | |||
max | min | max | min | max | min | max | ||
0.6 | 0.64 | 0.56 | 1.3 | 0.9 | 0.5 | 0.3 | 0.58 | 0.05 |
0.8 | 0.84 | 0.76 | 1.6 | 1.2 | 0.6 | 0.4 | 0.71 | 0.05 |
1 | 1.06 | 0.94 | 2 | 1.6 | 0.7 | 0.5 | 1 | 0.1 |
（1.2） | 0.26 | 1.14 | 2.3 | 1.9 | 0.8 | 0.6 | 1.2 | 0.1 |
1.4 | 1.46 | 1.34 | 2.7 | 2.3 | 0.9 | 0.7 | 1.4 | 0.1 |
（1.6） | 1.66 | 1.54 | 3.2 | 2.8 | 1.2 | 0.8 | 1.6 | 0.1 |
2 | 2.06 | 1.94 | 3.74 | 3.26 | 1.4 | 1 | 1.9 | 0.1 |
2.5 | 2.56 | 2.44 | 4.84 | 4.36 | 1.8 | 1.4 | 2.5 | 0.1 |
3 | 3.06 | 2.94 | 5.54 | 5.06 | 2 | 1.6 | 2.9 | 0.1 |
（3.5） | 3.58 | 3.42 | 6.59 | 6.01 | 2.3 | 1.9 | 3.1 | 0.3 |
4 | 4.08 | 3.92 | 7.39 | 6.81 | 2.6 | 2.2 | 3.8 | 0.3 |
5 | 5.08 | 4.92 | 9.09 | 8.51 | 3.2 | 2.8 | 4.7 | 0.3 |
6 | 6.08 | 5.92 | 11.35 | 10.65 | 3.84 | 3.36 | 6 | 03 |
8 | 8.1 | 7.9 | 14.35 | 13.65 | 5.04 | 4.56 | 8 | 0.3 |
10 | 10.1 | 9.9 | 17.35 | 16.65 | 6.24 | 5.76 | 9 | 0.3 |
12 | 12.12 | 11.88 | 21.42 | 20.58 | 8.29 | 7.71 | 11 | 0.3 |
（14） | 14.12 | 13.88 | 24.42 | 23.58 | 9.29 | 8.71 | 12.5 | 0.4 |
16 | 16.12 | 15.88 | 29.42 | 28.58 | 10.29 | 9.71 | 15.5 | 0.4 |
Where to buy GB/T867 Stainless Steel Round Head Rivets?just mail us info@topqualityalloy.com for ss rivets inquiry and order because we With professional factory best to guarantee the quality and lead time.
