M1.6-M10
RuiYang
GB/T818 Stainless Steel Cross Recessed Pan Head Screws with PMI test and sizes control for primary material bars and produced,Good Quality.
Owned factory better guarantee the Quality with good price,soonest delivery with seaworthy package suit for different ways carrying,One stop service in supply ss fasteners since 2007.
The details of Metric GB/T818 Stainless Steel Cross Recessed Pan Head Screws sizes and Stainless Steel Cross Recessed Pan Head bolts drawings as below:
d | M1.6 | M2 | M2.5 | M3 | （M3.5） | M4 | M5 | M6 | M8 | M10 | |
p | pitch | 0.35 | 0.4 | 0.45 | 0.5 | 0.6 | 0.7 | 0.8 | 1 | 1.25 | 1.5 |
b | min | 25 | 25 | 25 | 25 | 38 | 38 | 38 | 38 | 38 | 38 |
dk | max=DK | 3.2 | 4.0 | 5.0 | 5.6 | 7.00 | 8.00 | 9.50 | 12.00 | 16.00 | 20.00 |
min | 2.9 | 3.7 | 4.7 | 5.3 | 6.64 | 7.64 | 9.14 | 11.57 | 15.57 | 19.48 | |
k | max=DK | 1.30 | 1.60 | 2.10 | 2.40 | 2.60 | 3.10 | 3.70 | 4.6 | 6.0 | 7.50 |
min | 1.16 | 1.46 | 1.96 | 2.26 | 2.46 | 2.92 | 3.52 | 4.3 | 5.7 | 7.14 | |
Slot number | 0 | 0 | 1 | 1 | 2 | 2 | 2 | 3 | 4 | 4 | |
Welcome contact us for GB/T818 Stainless Steel Cross Recessed Pan Head Screws also stainless steel hex bolts and nuts,just mail us info@topqualityalloy.com with necessary information such as steel grade,sizes,quantity for our checking
GB/T818 Stainless Steel Cross Recessed Pan Head Screws with PMI test and sizes control for primary material bars and produced,Good Quality.
Owned factory better guarantee the Quality with good price,soonest delivery with seaworthy package suit for different ways carrying,One stop service in supply ss fasteners since 2007.
The details of Metric GB/T818 Stainless Steel Cross Recessed Pan Head Screws sizes and Stainless Steel Cross Recessed Pan Head bolts drawings as below:
d | M1.6 | M2 | M2.5 | M3 | （M3.5） | M4 | M5 | M6 | M8 | M10 | |
p | pitch | 0.35 | 0.4 | 0.45 | 0.5 | 0.6 | 0.7 | 0.8 | 1 | 1.25 | 1.5 |
b | min | 25 | 25 | 25 | 25 | 38 | 38 | 38 | 38 | 38 | 38 |
dk | max=DK | 3.2 | 4.0 | 5.0 | 5.6 | 7.00 | 8.00 | 9.50 | 12.00 | 16.00 | 20.00 |
min | 2.9 | 3.7 | 4.7 | 5.3 | 6.64 | 7.64 | 9.14 | 11.57 | 15.57 | 19.48 | |
k | max=DK | 1.30 | 1.60 | 2.10 | 2.40 | 2.60 | 3.10 | 3.70 | 4.6 | 6.0 | 7.50 |
min | 1.16 | 1.46 | 1.96 | 2.26 | 2.46 | 2.92 | 3.52 | 4.3 | 5.7 | 7.14 | |
Slot number | 0 | 0 | 1 | 1 | 2 | 2 | 2 | 3 | 4 | 4 | |
Welcome contact us for GB/T818 Stainless Steel Cross Recessed Pan Head Screws also stainless steel hex bolts and nuts,just mail us info@topqualityalloy.com with necessary information such as steel grade,sizes,quantity for our checking
